Square Hollow Sections (SHS) are often used for columns, however similarly to RHS sections, they are not often used as beams due to their shape that makes it difficult to bolt to other beams and vice versa. SHSs are often called “box sections”. An example is 100 x 100 x 10 SHS, which is 100 mm deep, 100 mm wide and the wall is 10 mm thick. Similar to RHS sections, hot rolled SHSs are made at the mill as one piece, whereas cold formed SHSs are made of a flat sheet rolled at right angles and welded. It is therefore easy to note the difference, as the cold rolled SHSs have a weld all along their length.
SHS
Type | Weight [kg/m] |
Height [mm] |
Width [mm] |
Wall thickness [mm] |
---|---|---|---|---|
20 x 20 x 2 SHS | 1.1 | 20 | 20 | 2 |
20 x 20 x 2.5 SHS | 1.3 | 20 | 20 | 2.5 |
25 x 25 x 2 SHS | 14 | 25 | 25 | 2 |
25 x 25 x 2.5 SHS | 1.7 | 25 | 25 | 2.5 |
25 x 25 x 3 SHS | 2.0 | 25 | 25 | 3 |
30 x 30 x 2 SHS | 1.7 | 30 | 30 | 2 |
30 x 30 x 2.5 SHS | 2.1 | 30 | 30 | 2.5 |
30 x 30 x 3 SHS | 2.5 | 30 | 30 | 3 |
40 x 40 x 2.5 SHS | 2.9 | 40 | 40 | 2.5 |
40 x 40 x 3 SHS | 3.4 | 40 | 40 | 3 |
40 x 40 x 3.2 SHS | 3.6 | 40 | 40 | 3.2 |
40 x 40 x 3.6 SHS | 4.0 | 40 | 40 | 3.6 |
40 x 40 x 4 SHS | 4.4 | 40 | 40 | 4 |
40 x 40 x 5 SHS | 5.3 | 40 | 40 | 5 |
50 x 50 x 2.5 SHS | 3.7 | 50 | 50 | 2.5 |
50 x 50 x 3 SHS | 4.4 | 50 | 50 | 3 |
50 x 50 x 3.2 SHS | 4.6 | 50 | 50 | 3.2 |
50 x 50 x 3.6 SHS | 5.1 | 50 | 50 | 3.6 |
50 x 50 x 4 SHS | 5.6 | 50 | 50 | 4 |
50 x 50 x 5 SHS | 6.9 | 50 | 50 | 5 |
50 x 50 x 6 SHS | 8.0 | 50 | 50 | 6 |
50 x 50 x 6.3 SHS | 8.3 | 50 | 50 | 6.3 |
60 x 60 x 2.5 SHS | 4.5 | 60 | 60 | 2.5 |
60 x 60 x 3 SHS | 5.3 | 60 | 60 | 3 |
60 x 60 x 3.2 SHS | 5.6 | 60 | 60 | 3.2 |
60 x 60 x 3.6 SHS | 6.3 | 60 | 60 | 3.6 |
60 x 60 x 4 SHS | 6.9 | 60 | 60 | 4 |
60 x 60 x 5 SHS | 8.4 | 60 | 60 | 5 |
60 x 60 x 6 SHS | 9.9 | 60 | 60 | 6 |
60 x 60 x 6.3 SHS | 10.3 | 60 | 60 | 6.3 |
60 x 60 x 8 SHS | 12.5 | 60 | 60 | 8 |
70 x 70 x 3 SHS | 6.2 | 70 | 70 | 3 |
70 x 70 x 3.2 SHS | 6.6 | 70 | 70 | 3.2 |
70 x 70 x 3.6 SHS | 7.4 | 70 | 70 | 3.6 |
70 x 70 x 4 SHS | 8.2 | 70 | 70 | 4 |
70 x 70 x 5 SHS | 10.0 | 70 | 70 | 5 |
70 x 70 x 6 SHS | 11.8 | 70 | 70 | 6 |
70 x 70 x 6.3 SHS | 12.3 | 70 | 70 | 6.3 |
70 x 70 x 8 SHS | 15.0 | 70 | 70 | 8 |
80 x 80 x 3 SHS | 7.2 | 80 | 80 | 3 |
80 x 80 x 3.2 SHS | 7.6 | 80 | 80 | 3.2 |
80 x 80 x 3.6 SHS | 8.5 | 80 | 80 | 3.6 |
80 x 80 x 4 SHS | 9.4 | 80 | 80 | 4 |
80 x 80 x 5 SHS | 11.6 | 80 | 80 | 5 |
80 x 80 x 6 SHS | 13.6 | 80 | 80 | 6 |
80 x 80 x 6.3 SHS | 14.2 | 80 | 80 | 6.3 |
80 x 80 x 8 SHS | 17.8 | 80 | 80 | 8 |
90 x 90 x 5 SHS | 13.1 | 90 | 90 | 5 |
90 x 90 x 6 SHS | 15.5 | 90 | 90 | 6 |
90 x 90 x 6.3 SHS | 16.2 | 90 | 90 | 6.3 |
90 x 90 x 8 SHS | 20.1 | 90 | 90 | 8 |
100 x 100 x 3.6 SHS | 10.8 | 100 | 100 | 3.6 |
100 x 100 x 4 SHS | 11.9 | 100 | 100 | 4 |
100 x 100 x 5 SHS | 14.7 | 100 | 100 | 5 |
100 x 100 x 6 SHS | 17.4 | 100 | 100 | 6 |
100 x 100 x 6.3 SHS | 18.2 | 100 | 100 | 6.3 |
100 x 100 x 8 SHS | 22.6 | 100 | 100 | 8 |
100 x 100 x 10 SHS | 27.4 | 100 | 100 | 10 |
120 x 120 x 4 SHS | 14.4 | 120 | 120 | 4 |
120 x 120 x 5 SHS | 18.0 | 120 | 120 | 5 |
120 x 120 x 6 SHS | 21.2 | 120 | 120 | 6 |
120 x 120 x 6.3 SHS | 22.2 | 120 | 120 | 6.3 |
120 x 120 x 8 SHS | 27.6 | 120 | 120 | 8 |
120 x 120 x 10 SHS | 33.7 | 120 | 120 | 10 |
120 x 120 x 12 SHS | 39.5 | 120 | 120 | 12 |
120 x 120 x 12.5 SHS | 40.9 | 120 | 120 | 12.5 |
140 x 140 x 5 SHS | 21.0 | 140 | 140 | 5 |
140 x 140 x 6 SHS | 24.9 | 140 | 140 | 6 |
140 x 140 x 6.3 SHS | 26.1 | 140 | 140 | 6.3 |
140 x 140 x 8 SHS | 32.6 | 140 | 140 | 8 |
140 x 140 x 10 SHS | 40.0 | 140 | 140 | 10 |
140 x 140 x 12 SHS | 47.0 | 140 | 140 | 12 |
140 x 140 x 12.5 SHS | 48.7 | 140 | 140 | 12.5 |
150 x 150 x 5 SHS | 22.6 | 150 | 150 | 5 |
150 x 150 x 6 SHS | 26.8 | 150 | 150 | 6 |
150 x 150 x 6.3 SHS | 28.1 | 150 | 150 | 6.3 |
150 x 150 x 8 SHS | 35.1 | 150 | 150 | 8 |
150 x 150 x 10 SHS | 43.1 | 150 | 150 | 10 |
150 x 150 x 12 SHS | 50.8 | 150 | 150 | 12 |
150 x 150 x 12.5 SHS | 52.7 | 150 | 150 | 12.5 |
150 x 150 x 16 SHS | 65.2 | 150 | 150 | 16 |
160 x 160 x 5 SHS | 24.1 | 160 | 160 | 5 |
160 x 160 x 6 SHS | 28.7 | 160 | 160 | 6 |
160 x 160 x 6.3 SHS | 30.1 | 160 | 160 | 6.3 |
160 x 160 x 8 SHS | 37.6 | 160 | 160 | 8 |
160 x 160 x 10 SHS | 46.3 | 160 | 160 | 10 |
160 x 160 x 12 SHS | 54.6 | 160 | 160 | 12 |
160 x 160 x 12.5 SHS | 56.6 | 160 | 160 | 12.5 |
160 x 160 x 16 SHS | 70.2 | 160 | 160 | 16 |
180 x 180 x 5 SHS | 27.3 | 180 | 180 | 5 |
180 x 180 x 6 SHS | 32.5 | 180 | 180 | 6 |
180 x 180 x 6.3 SHS | 34.0 | 180 | 180 | 6.3 |
180 x 180 x 8 SHS | 42.7 | 180 | 180 | 8 |
180 x 180 x 10 SHS | 52.5 | 180 | 180 | 10 |
180 x 180 x 12 SHS | 62.1 | 180 | 180 | 12 |
180 x 180 x 12.5 SHS | 64.4 | 180 | 180 | 12.5 |
180 x 180 x 16 SHS | 80.2 | 180 | 180 | 16 |
200 x 200 x 5 SHS | 30.4 | 200 | 200 | 5 |
200 x 200 x 6 SHS | 36.2 | 200 | 200 | 6 |
200 x 200 x 6.3 SHS | 38.0 | 200 | 200 | 6.3 |
200 x 200 x 8 SHS | 47.7 | 200 | 200 | 8 |
200 x 200 x 10 SHS | 58.8 | 200 | 200 | 10 |
200 x 200 x 12 SHS | 69.6 | 200 | 200 | 12 |
200 x 200 x 12.5 SHS | 72.3 | 200 | 200 | 12.5 |
200 x 200 x 16 SHS | 90.3 | 200 | 200 | 16 |
220 x 220 x 6 SHS | 40.0 | 220 | 220 | 6 |
220 x 220 x 6.3 SHS | 41.9 | 220 | 220 | 6.3 |
220 x 220 x 8 SHS | 52.7 | 220 | 220 | 8 |
220 x 220 x 10 SHS | 65.1 | 220 | 220 | 10 |
220 x 220 x 12 SHS | 77.2 | 220 | 220 | 12 |
220 x 220 x 12.5 SHS | 80.1 | 220 | 220 | 12.5 |
220 x 220 x 16 SHS | 100.0 | 220 | 220 | 16 |
250 x 250 x 5 SHS | 38.3 | 250 | 250 | 5 |
250 x 250 x 6 SHS | 45.7 | 250 | 250 | 6 |
250 x 250 x 6.3 SHS | 47.9 | 250 | 250 | 6.3 |
250 x 250 x 8 SHS | 60.3 | 250 | 250 | 8 |
250 x 250 x 10 SHS | 74.5 | 250 | 250 | 10 |
250 x 250 x 12 SHS | 88.5 | 250 | 250 | 12 |
250 x 250 x 12.5 SHS | 91.9 | 250 | 250 | 12.5 |
250 x 250 x 16 SHS | 115.0 | 250 | 250 | 16 |
260 x 260 x 6 SHS | 47.6 | 260 | 260 | 6 |
260 x 260 x 6.3 SHS | 49.9 | 260 | 260 | 6.3 |
260 x 260 x 8 SHS | 62.8 | 260 | 260 | 8 |
260 x 260 x 10 SHS | 77.7 | 260 | 260 | 10 |
260 x 260 x 12 SHS | 92.2 | 260 | 260 | 12 |
260 x 260 x 12.5 SHS | 95.8 | 260 | 260 | 12.5 |
260 x 260 x 16 SHS | 120.0 | 260 | 260 | 16 |
300 x 300 x 6 SHS | 55.1 | 300 | 300 | 6 |
300 x 300 x 6.3 SHS | 57.8 | 300 | 300 | 6.3 |
300 x 300 x 8 SHS | 72.8 | 300 | 300 | 8 |
300 x 300 x 10 SHS | 90.2 | 300 | 300 | 10 |
300 x 300 x 12 SHS | 107.0 | 300 | 300 | 12 |
300 x 300 x 12.5 SHS | 112.0 | 300 | 300 | 12.5 |
300 x 300 x 16 SHS | 141.0 | 300 | 300 | 16 |
350 x 350 x 8 SHS | 85.4 | 350 | 350 | 8 |
350 x 350 x 10 SHS | 106.0 | 350 | 350 | 10 |
350 x 350 x 12 SHS | 126.0 | 350 | 350 | 12 |
350 x 350 x 12.5 SHS | 131.0 | 350 | 350 | 12.5 |
350 x 350 x 16 SHS | 166.0 | 350 | 350 | 16 |
400 x 400 x 8 SHS | 97.9 | 400 | 400 | 8 |
400 x 400 x 10 SHS | 122.0 | 400 | 400 | 10 |
400 x 400 x 12 SHS | 145.0 | 400 | 400 | 12 |
400 x 400 x 12.5 SHS | 151.0 | 400 | 400 | 12.5 |
400 x 400 x 16 SHS | 191.0 | 400 | 400 | 16 |
400 x 400 x 20 SHS | 235.0 | 400 | 400 | 20 |
